Spec

• Model number: EO-600 V
• Capacity (L): 150
• Temperature adjustment range: R.T. + 20 to 300 °C
• Maximum temperature arrival time: about 90 minutes
• Temperature distribution width: 25 °C (at 300 °C)
• Temperature control method: PID control and SSR output
• Additional function: Timer (ON/OFF timer, SV start/ON/OFF timer)
• Safety device: Indep***ent overheating prevention device (Operation temperature Digital settable), overcurrent breaker burnout mechanism (Heater OFF when sensor is disconnected)
• Heater capacity: 1400W
• Temperature sensor/Overtemperature protection sensor: K class thermocouple
• Inner dimensions: 600 x 500 x 500mm
• pitch TANA/number of step: 35 mm/13 Dan
• Exterior/Interior: Steel powder coating/Stainless steel (SUS304)
• Air outlet: φ32mm x 2 pieces
• Outer dimensions: 700 x 610 x 830mm
• Weight: about 50kg
• Power supply: AC100V 50/60Hz cord length : 2 m (3P plug)
• rated current: 14.5 A
• shelf board, load tolerance: 5kg
• Accessories: shelf board x 2 pieces/shelf board rail x 2 sets
• This product can be ***d for validation services (IQ/OQ).　Please contact us.
• ** Validation Service is a service that performs installation qualification (IQ) and operation performance qualification (OQ) at the customer's site and submits inspection documents.
