63-6680-45 24V ac 2 Output Through Hole PCB Transformer, 12VA 504-537
Product Description
Product Model: 63-6680-45Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-6680-45
Product Brand: RS PRO
Features
- Primary Side 230 Vac Transformer
- Spare Pin for Fully Coated Bobbin Board Mounting 100% Electrical Performance/Flash Tested BS3535 and EN 60 742 Verified
Spec
- Secondary Voltage Rating:24V ac
- Power Rating:12VA
- Primary Voltage Rating:230V ac
- Number of Outputs:2
- Length:54mm
- Width:45mm
- Depth:41mm
- Dimensions:54 x 45 x 41mm
- Weight:400g
- Mounting Type:Through Hole
- Minimum Operating Frequency:50Hz
- Maximum Operating Frequency:60Hz
- CODE No.:504-537
