63-3120-66 Consul XB Series for Double Stacking Printed Plates H = 10 mm Pitch 1.27 mm 40 Pin (10 Pins) XB11040P
Electronic/Electrical Parts and Controll Equipments

63-3120-66 Consul XB Series for Double Stacking Printed Plates H = 10 mm Pitch 1.27 mm 40 Pin (10 Pins) XB11040P

model: 63-3120-66
brand: MAC EIGHT CO., LTD

Product Description

Product Model: 63-3120-66Product Brand: MAC EIGHT CO., […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-3120-66
Product Brand: MAC EIGHT CO., LTD

Features

  • Pitch: 1.27 mm (max. 40P connection), 2.54 mm (max. 20P connection) Materials: Pin ... Beryllium Copper Nickel Underlay Gold Plating Resin Section ... LCP Resin Black
  • Rated Current: 1 A
  • Rated Voltage: 125 V AC, DC
  • Contact Resistance: 30 mΩ or Less
  • Insulation Resistance: 500 MΩ or More
  • Insulation Voltage: 1000 V, AC, DC1 minute
  • Print Plate Compatible Through Hole: 0.8~0.9φTH Finishing Diameter (Contact Side)
  • Print Plate Compatible Plate Thickness: 0.8~1.6 t
  • Operating Temperature Range: -40 to +125°C
  • Operating Humidity Range: 0~85%rh (No Condensation)
  • Number of times of ***: 50 times or less
  • This product can be ***d with 1 male or female. Since the socket is unnecessary, the height between the PC plate and the PC plate can be reduced. (1 mm to 10 mm) XB series soldering side also has spring property, so the product does not tilt and can stand upright. Both sides can also be soldered. Due to the rapid oxidation of copper, the connecting side cannot be ***d for copper through hole substrates.
