• LED Display Expansion Board for MyoWare Muscle Sensor
• Used in conjunction with the MyoWare muscle sensor, the magnitude of the measured signal is shown as a bar graph with 10 blue LED segments. The more muscle activation measured, the longer the lit LED lights. Power is supplied from this LED shield, but can be controlled by the power switch on the MyoWare muscle sensor.
• [Note]
• *This shield can be stacked on top, so solder a 1x3 Ospin header and plug it into the sensor board.
• *The MyoWare Power Shield and the MyoWare LED Shield can both provide power, but the voltage applied is slightly different. Therefore, do not *** both of these shields at the same time.
