63-6628-39 Cable Marker White TRSA-1019E1U
Electronic/Electrical Parts and Controll Equipments

63-6628-39 Cable Marker White TRSA-1019E1U

model: 63-6628-39
brand: TE Connectivity

Product Description

Product Model: 63-6628-39Product Brand: TE Connectivity […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-6628-39
Product Brand: TE Connectivity

Features

  • Heatshrink Pre-Printed Cable Marker
  • An irradiated polyolefin heat-shrink cable marker that shrinks to 33% of its original diameter when heated above 120 °C. The leg*** is printed in black on a white background so it can be clearly identified in low light. This cable marker is highly flame retardant (> 5 seconds burn time), compatible with ASTM B876.
  • Features and Benefits:; Available in 3 sizes: - Size 3// 1: Nominal inside diameter 3 mm - Size 6// 2: Nominal inside diameter 6 mm - Size 12// 4: Nominal inside diameter 12 mm; Continuous temperature range: -55 to +135 °C (maximum +300 °C for short periods); Shrinkage ratio: 3:1; Easy and safe installation; Resistance suitable for common fluids

Spec

  • Quantity: 1 bag (100 pieces)
  • Fixing method: Heat shrink tube
  • Leg***: U
  • Minimum cable diameter: 2 mm
  • Maximum cable diameter: 6 mm
  • Color: White
  • Amount: 100
  • Material: Polyolefin
  • Operating temperature Min: -55 degrees C
  • Operating temperature Max: + 135 degrees C
  • Durable: Flames, fluids
  • Operating temperature range: -55 to + 135 degrees C
  • RoHS compliance status: Compliance
  • Securities Code: 393 - 093
