63-6594-40 Toggle Switch On-On SPDT Panel Mount 10 A @ 250 V ac, 15 A @ 125 V ac ET115D12-Z
Electronic/Electrical Parts and Controll Equipments

63-6594-40 Toggle Switch On-On SPDT Panel Mount 10 A @ 250 V ac, 15 A @ 125 V ac ET115D12-Z

model: 63-6594-40
brand: Copal Electronics

Product Description

Product Model: 63-6594-40Product Brand: Copal Electroni […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-6594-40
Product Brand: Copal Electronics

Features

  • Use of nameplate and waterproof cap is optional.
  • Small Toggle Switch ET Series (15 A)
  • The contact structure housing with reduced chattering and bouncing time as much as possible ***s self-digestible phenol resin with excellent heat resistance, arc resistance and tracking resistance. The terminals are solder and screw terminals.

Spec

  • Number of Pieces: 1
  • contact configuration: SPDT
  • Switch Operation: On-On
  • Contact current rating: 10 A @ 250 V ac, 15 A @ 125 V ac
  • Mounting Type: Panel Mount
  • Terminal Type: Solder Tag
  • Actuator Length: 17 mm
  • Contact resistance: 20 mΩ
  • Operating temperature range: -25 → +85°C
  • RoHS Compliance Status: Compliance
  • Securities Code: 222-825
