63-6592-54 Shunt Resistor Metal Foil Resistor 3216 size 0.25 W 75 m.OMEGA. +/- 1% TL2BR0751
model:
63-6592-54
brand:
TE Connectivity
Product Description
Product Model: 63-6592-54Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-6592-54
Product Brand: TE Connectivity
Features
- TL2B Series SMD Current Detector Resistor
- Type 1206 Up to 0.25 W @ 70 °C Low resistance shunt resistor that acts as a current sensor Suitable for a wide range of values: R01 → R1
- TE Connectivity TL2B Series is a high power low resistance metal chip shunt resistor that is ***d for various current detection applications. The TL2B series has a unique metal resistance element and solder over the barrier layer for a longer terminal life. TL2B is best ***d in the automotive industry for current detection inside electric trains (EMU).
Spec
- Quantity: 1 bag (5 pieces)
- Resistance: 75 m.OMEGA.
- Package/Case: 1206
- Tolerance: +/- 1%
- Rated power: 0.25 W
- Temperature factor: +/- 75 ppm/deg.
- Technology: Metal foil
- Dimensions: 3.2 x 1.6 x 0.6 mm
- Length: 3.2 mm
- Depth: 1.55 mm
- Height: 0.6 mm
- Series: TL2B
- Operating temperature Min: -65 degrees C
- Operating temperature Max: + 170 degrees C
- Case Style: Mold
- RoHS compliance status: Compliance
- Securities Code: 219 -942
