3-8052-21 Fume Hood (2 Position Switchable Type, Variable Air Volume VAV Type) Deep 1200 x 980 x 2250 mm ABDVII-1200
Product Description
Product Model: 3-8052-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-8052-21
Product Brand: AS ONE Corporation
Features
- The air volume is switched and controlled in two stages according to the sash opening to achieve safety, energy saving and comfort at the same time.
- This type is equipped with a switch to change the exhaust air volume in the middle of opening and closing the sash, and controls the exhaust air volume in two stages.
- While the sash is closed, wasteful exhaust can be suppressed, saving energy.
- We reduced the installation cost by limiting to a simple air volume switching function that allows the sash to be either open (HI) or closed (Lo).
- For Acid/Alkali
- For Organic
Spec
- specifications: deep
- External Dimensions (mm): 1200 x 980 x 2250
- Inner Dimensions (mm): 950 x 755 x 1200
- Weight (approx. kg): 330
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- Automatic air flow control: switchable automatic exhaust air flow control device set
- [Exhaust]
- Air volume (m3/min): 13 (4)
- Duct Connection Port: 150 A
- Required Duct Diameter (φmm): 200
- Attached Facility: Fluorescent Lamp (Piece)/20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
