Electronic/Electrical Parts and Controll Equipments
63-6547-09 KEMET 100μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 30 x 45mm +85°C 30mm 45mm ALP20A101BB400
Product Description
Product Model: 63-6547-09Product Brand: KEMET Features […]
Contact Us
Product Details
Product Model: 63-6547-09
Product Brand: KEMET
Features
- ALP20 Series
- IEC384-4 (Long Life) compliant aluminum electrolytic capacitors for mounting boards. The case has vents and insulated sleeves. Due to the presence of electrolytes, terminals 2, 3, and 4 may have negative terminal potentials. For mechanical connections only. It is recomm***ed that you solder these terminals to the board on the insulation pad.
Spec
- Quantity:1piece
- Capacitance : 100µF
- Voltage : 400V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 30 x 45mm
- Height : 45mm
- Length : 45mm
- Minimum Operating Temperature : -40°C
- Diameter : 30mm
- Maximum Operating Temperature : +85°C
- Lifetime : 15000 h @ +85 °C/400V dc/Ir
- Series : ALP20
- Leakage Current : 0.24 mA
- CODE No.:105-543
