63-5179-76 ON Semiconductor, 18V Zener Diode 5% 1 W Through Hole 2-Pin DO-41 1N4746A
model:
63-5179-76
brand:
ON Semiconductor
Product Description
Product Model: 63-5179-76Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-5179-76
Product Brand: ON Semiconductor
Features
- Zener Diodes 1W, 1N4728A - 1N4758A Series, Fairchild Semiconductor
Spec
- Quantity：1bag(100pieces)
- Nominal Zener Voltage : 18V
- Number of Elements per Chip : 1
- Maximum Power Dissipation : 1 W
- Package Type : DO-41
- Zener Type : General Purpose
- Zener Voltage Tolerance : 5%
- Pin Count : 2
- Test Current : 14mA
- Maximum Zener Impedance : 20Ω
- Maximum Reverse Leakage Current : 5µA
- Length : 5.2mm
- Diameter : 2.72mm
- Dimensions : 2.72 (Dia.) x 5.2 Lmm
- Maximum Operating Temperature : +200 °C
- CODE No.:917-5443
