Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 3 points at 37 degrees Celsius
• Temperature setting range: room temperature + 5 ~ 80 degrees C
• Tank capacity: 27 L
• Accuracy of humidity distribution: within +/- 0.3 degrees C (This is the value at the set water temperature of 40 degrees Celsius and room temperature of 20 degrees Celsius.)
• Pump capacity (50/60 Hz): 11/12 L/min
• Temperature control system: Heater PID control (SSR output)
• Safety functions: Self-diagnosis function, earth leakage breaker, abnormal heating prevention device, float type empty heating prevention, external output, Timer function, program function
• Power: 100 VAC, 50/60 Hz
• Maximum operating current: 14 A
• Power cord: 3P plug + adapter
• Material: Body/Steel, Water Tank/SUS 304 + Glass
• Weight: 22 kg
• Accessories: 1 shelf, 4 shelf receptacles, 1 stand, 1 clamp, 1 clamp holder
• External dimensions: 505 x 360 x 370 mm
• Internal dimensions: 300 x 300 x 300 mm
• Effective inside dimensions: 225 mm
• *The effective inner dimension indicates the maximum depth when using the shelf board.
• *The unit itself has no cooling function. A cooling coil (1 -5457 -11) and cooling water circulator (1 -5469 -41) sold separately can be ***d in combination to control temperatures below room temperature.
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
