Electronic/Electrical Parts and Controll Equipments
63-5161-28 EPCOS 33nF Polypropylene Capacitor PP 1.6 kV dc, 600 V ac ±5% Tolerance B32672L Series B32672L1333J000
Product Description
Product Model: 63-5161-28Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-5161-28
Product Brand: EPCOS
Features
- B32671L .. B32673L Series Metallized Polypropylene Film Capacitors (MKP). Wound capacitor technology with Epoxy resin sealing. Very high AC Voltages for all frequency ranges Very small dimensions High peak voltage for short time periods High peak current High pulse withstand capability RoHS-compatible Halogen-free capacitors available on request Applications include Electronic ballasts (resonant circuits); Switched Mode Power Supplies; High-frequency AC loads and Pulse circuits
Spec
- Quantity：1bag(5pieces)
- Capacitance : 33nF
- Voltage : 1.6 kV dc, 600 V ac
- Tolerance : ±5%
- Series : B32672L
- Lead Pitch : 15mm
- Length : 18mm
- Depth : 9mm
- Height : 17.5mm
- Dimensions : 18 x 9 x 17.5mm
- Dielectric : Metallized Polypropylene
- Minimum Operating Temperature : -55°C
- CODE No.:882-9212
