63-5152-66 Arcol 20Ω 100W Fixed Resistor ±1% ±50ppm/°C AP101 20R F 50PPM
Product Description
Product Model: 63-5152-66Product Brand: Arcol Features […]
Contact Us
Product Details
Product Model: 63-5152-66
Product Brand: Arcol
Features
- AP101 Series 100W TO-247 High Power Resistors. The AP101 series non-inductive TO-247 style thick film Power Resistors capable of dissipating 100 watts. The AP101 series benefits from new material technologies and an extremely low thermal resistance. TO-247 style power package capable of dissipating 100 watts Extremely low thermal resistance at 0.9°C/W resistor hotspot to metal tab Thick Film design Single screw mounting to heat sink Moulded case for protection Electrically isolated case Non-Inductive design Recomm***ed: The *** of thermal grease between metal tab and heat sink
Spec
- Quantity：1piece
- Resistance : 20Ω
- Power Rating : 100W
- Tolerance : ±1%
- Technology : Non-Inductive
- Series : AP101
- Package/Case : TO-247
- Lead Pitch : 10.42mm
- CODE No.:862-5720
