63-5152-34 Nichicon 4700μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 22 x 50mm +105°C 22mm 10mm UVY1J472MRD
Product Description
Product Model: 63-5152-34Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-5152-34
Product Brand: NICHICON
Features
- Nichicon VY Series General Purpose Electrolytic Capacitors. Nichicon VY series aluminium electrolytic capacitors are miniature sized, low impedance, high reliability capacitors for switching power supplies. Features ; Benefits:. Lifetime rating of 1000 hours @ 105°C. High ripple current and temperature range
Spec
- Quantity：1piece
- Capacitance : 4700µF
- Voltage : 63V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 22 x 50mm
- Height : 50mm
- Minimum Operating Temperature : -55°C
- Diameter : 22mm
- Maximum Operating Temperature : +105°C
- Lifetime : 1000h
- Series : VY
- Leakage Current : 8883 μA
- CODE No.:862-4187
