Electronic/Electrical Parts and Controll Equipments
63-5152-22 Nichicon 100μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 x 11mm +85°C 6.3mm 2.5mm UVR1V101MED
Product Description
Product Model: 63-5152-22Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-5152-22
Product Brand: NICHICON
Features
- Nichicon VR Series General Purpose Electrolytic Capacitors. Nichicon VR Series Aluminium Electrolytic Capacitors are high reliability capacitors which have a rated life up to 2000 hours. The VR series capacitors offer a high temperature range, high voltage, low impedance and high ripple current. Features ; Benefits:. High reliability High ripple current Long life up to 2000 hours Lead free reflow soldering Capacitance values up to 33000 μF
Spec
- Quantity：1piece
- Capacitance : 100µF
- Voltage : 35V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 6.3 x 11mm
- Height : 11mm
- Minimum Operating Temperature : -40°C
- Diameter : 6.3mm
- Maximum Operating Temperature : +85°C
- Lifetime : 2000h
- Series : VR
- Leakage Current : 105 μA
- CODE No.:862-3323
