63-5145-66 Nichicon 150μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 35mm +105°C 22mm 10mm LGW2G151MELZ35
Product Description
Product Model: 63-5145-66Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-5145-66
Product Brand: NICHICON
Features
- Nichicon High Ripple Current Snap-In, GW Series. Nichicon GW Series Snap-In Aluminium Electrolytic Capacitors can withstand 3000 hours of rated ripple current application. The snap-in terminal GW Series Aluminium Electrolytic Capacitors from Nichicon offer a large capacitance range with voltages ranging from 200 to 450V. These high performance capacitors have a wide temperature range which is ideal for applications such as uninterruptible power supplies, electric pump motors, and AC servomotors. Snap-In terminals Endurance rating ripple current 3000 hours guaranteed PET sleeve (non PVC) Lead-free terminal plating
Spec
- Quantity：1piece
- Capacitance : 150µF
- Voltage : 400V dc
- Mounting Type : Through Hole
- Technology : Electrolytic
- Dimensions : 22 (Dia.) x 35mm
- Height : 35mm
- Minimum Operating Temperature : -25°C
- Diameter : 22mm
- Maximum Operating Temperature : +105°C
- Lead Pitch : 10mm
- Series : GW
- Leakage Current : 0.73 mA
- CODE No.:846-7026
