63-5142-66 RS Pro 1 Gang Rotary Conductive Plastic Potentiometer with a 8 mm Dia. Shaft, 5kΩ, ±20%, 2W, Linear 842-7169
Product Description
Product Model: 63-5142-66Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-5142-66
Product Brand: RS PRO
Features
- RS NP Conductive Plastic Hollow Shaft Potentiometers. This series of RS hollow shaft potentiometers are constructed from a long life conductive plastic and feature a sturdy low profile body. No coupling is needed due to easy mounting directly onto the shaft. With a rotational life of 4,000,000 shaft revolutions, these hollow potentiometers also offer noise free output due to a precious metal wiper. 360° mechanical rotation angle ±20% standard resistance tolerance D shaped shaft
Spec
- Quantity：1piece
- Potentiometer Type : Rotary
- Maximum Resistance : 5kΩ
- Number of Gangs : 1
- Power Rating : 2W
- Electrical Taper : Linear
- Element Material : Conductive Plastic
- Mounting Type : Panel Mount
- Termination Style : Solder
- Shaft Diameter : 8 mm
- Tolerance : ±20%
- Series : NP32HS
- CODE No.:842-7169
