Features

• UL 60950, UL60601 (3rd Ed). Murata 2W Dual Output Isolated DC-DC Converter - MGJ2 Series. The Murata MGJ2 series of DC-DC converters is ideal for powering high side and low side gate drive circuits in bridge circuits for IGBTs and Mosfets. These isolated DC-DC converters offer a choice of asymmetric output voltages allowing optimal drive levels for best system efficiency and EMI. The MGJ2 series of isolated power supplies is characterised for high isolation and dv/dt requirements commonly seen in bridge circuits ***d in motor drives and inverters. The industrial grade temperature rating and construction of the MGJ2 guarantees long service life and reliability. Optimised bipolar output voltages for IGBT/ Mosfet gate drives Power density 0.81W/cm³ 5.2kVDC isolation test voltage Ultra low coupling capacitance Footprint 1.96cm² SIP package style 5V, 12V, 15V ; 24V inputs +15V/-5V, +15V/-8.7V ; +20V/-5V outputs Operation to 100 oC Characterised dv/dt immunity Characterised partial discharge performance
