63-5121-38 560Ω 1206 Thick Film SMD Resistor ±5% 0.5W - CRGH1206J560R CRGH1206J560R
model:
63-5121-38
brand:
TE Connectivity
Product Description
Product Model: 63-5121-38Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-5121-38
Product Brand: TE Connectivity
Features
- 1206 Format CRGH Series Resistor 0.5W. CRGH series chip resistors are the version of the CRG in high Power version, for the same case size they are twice on the power rating at 70°C CRGH series chip resistors are suitable for most applications, including high frequency operation, owing to the short lead structure and low capacitance
Spec
- Quantity：1bag(100pieces)
- Resistance : 560Ω
- Technology : Thick Film
- Package/Case : 1206 (3216M)
- Tolerance : ±5%
- Power Rating : 0.5W
- Temperature Coefficient : ±200ppm/°C
- Series : CRGH
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +155°C
- CODE No.:807-1259
