63-5121-05 ON Semiconductor GBU6D, Bridge Rectifier, 6A 200V, 4-Pin GBU GBU6D
model:
63-5121-05
brand:
ON Semiconductor
Product Description
Product Model: 63-5121-05Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-5121-05
Product Brand: ON Semiconductor
Features
- UL, E258596. Bridge Rectifiers Single-In-Line Package PCB Mounting, GBU Series. GBU series bridge rectifiers in SIL PCB Mounting package from Fairchild Semiconductor. Glass Passivated Single-Phase Bridge Rectifier High surge current capability Wire Lead Structure for Printed Circuit Board (PCB) mounting
Spec
- Quantity：1set(20pieces)
- Bridge Type : Single Phase
- Peak Average Forward Current : 6A
- Peak Reverse Repetitive Voltage : 200V
- Mounting Type : Through Hole
- Package Type : GBU
- Pin Count : 4
- Configuration : Single
- Peak Non-Repetitive Forward Surge Current : 175A
- Maximum Operating Temperature : +150 °C
- Minimum Operating Temperature : -55 °C
- Peak Forward Voltage : 1V
- Peak Reverse Current : 500µA
- Length : 22.3mm
- Dimensions : 22.3 x 3.56 x 18.8mm
- CODE No.:806-7149
