63-5114-01 RS PRO SPDT Non-Latching Relay PCB Mount, 5V dc Coil, 20A 800-4495
Product Description
Product Model: 63-5114-01Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-5114-01
Product Brand: RS PRO
Features
- UL (File no. E134517), TUV (File no. R9659294), CQC (File no. CQC02001001955). Miniature High Power Relays. Contacts: 1 Form C, SPDT 5 mm pinning 4 kV dielectric strength (between coil and contacts)
Spec
- Quantity：1piece
- Coil Voltage : 5V dc
- Coil Power : 530mW
- Coil Resistance : 47 Ω
- Isolation Coil To Contact : 4kV ac
- Contact Configuration : SPDT
- Mounting Type : PCB Mount
- Switching Current : 20A
- Terminal Type : Through Hole
- Number of Poles : 1
- Maximum Switching Voltage AC : 277V ac
- Maximum Switching Voltage DC : 30V dc
- Maximum Switching Power AC : 5.54 kVA
- CODE No.:800-4495
