63-5113-77 Murata 100 μH ±10% Leaded Inductor, Max SRF:1kHz, 350mA Idc, 1.1Ω Rdc 1100R 11R104C
model:
63-5113-77
brand:
Murata Power Solutions
Product Description
Product Model: 63-5113-77Product Brand: Murata Power So […]
Contact Us
Product Details
Product Model: 63-5113-77
Product Brand: Murata Power Solutions
Features
- Murata 1100R Series Radial Lead Inductors. 1100R Series Inductors are general purpose range of inductors suitable for low to medium current applications Low DC resistance Up to 3.0A Idc 1.0 to 470μH Inductance
Spec
- Quantity：1bag(5pieces)
- Inductance : 100 μH
- Maximum DC Current : 350mA
- Maximum DC Resistance : 1.1Ω
- Tolerance : ±10%
- Diameter : 5mm
- Height : 7.5mm
- Dimensions : 5 (Dia.) x 7.5mm
- Maximum Self Resonant Frequency : 1kHz
- Lead Pitch : 2mm
- Series : 1100R
- Lead Diameter : 0.5mm
- CODE No.:800-4350
