63-5104-17 Wurth WE-PD Series Shielded Wire-wound SMD Inductor 100 μH ±20% 1.5A Idc 7447714101
model:
63-5104-17
brand:
Wurth Elektronik
Product Description
Product Model: 63-5104-17Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 63-5104-17
Product Brand: Wurth Elektronik
Features
- Plastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction. WE-PD Series Magnetically Shielded Wire Wound Chokes. Wurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recomm***ed solder profile: Reflow. Operating temperature -40 to +125°C. Applications. Switching regulators with low operating voltages Integrated DC-DC converters Switching regulators with high efficiency (>86%) Graphic cards
Spec
- Quantity：1piece
- Inductance : 100 μH
- Maximum DC Current : 1.5A
- Length : 10mm
- Depth : 10mm
- Height : 5mm
- Dimensions : 10 x 10 x 5mm
- Shielded : Yes
- Tolerance : ±20%
- Maximum DC Resistance : 198mΩ
- Series : WE-PD
- Maximum Self Resonant Frequency : 5.9MHz
- Minimum Operating Temperature : -40°C
- CODE No.:789-6952
