63-5091-96 Mean Well 15W 1 Output Embedded Switch Mode Power Supply SMPS, 3A, 5V dc Open Frame EPS-15-5
Electronic/Electrical Parts and Controll Equipments

63-5091-96 Mean Well 15W 1 Output Embedded Switch Mode Power Supply SMPS, 3A, 5V dc Open Frame EPS-15-5

model: 63-5091-96
brand: Mean Well

Product Description

Product Model: 63-5091-96Product Brand: Mean Well Featu […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-5091-96
Product Brand: Mean Well

Features

  • TUV EN60950-1. 3. Mean Well EPS-15 Series 15W AC-DC Open Frame Miniature Switch Mode Power Supply. The Mean Well EPS-15 Series delivers compact size, high efficiency and is cost efficient. This Switch Mode, Open Frame Power Supply is 37% smaller than previous comparable products, with working efficiency increased by 2∼8%. The EPS-15 Power Supply has a high efficiency up to 85% and they can be cooled by Free air convection. These Mean Well Power Supplies have a very low no load power consumption of ˂0.3W, conforming to the requirements of ErP norm and Energy Star for *** systems. The EPS-15 is ideal for applications such as Factory Automation, Electrical ot Mechanical equipment and for all applications that requires a low no load power consumption. Compact PCB Size No load Power consumption ˂0.3W High efficiency up to 85% Universal AC input 24mm Low profile Cooling by free air convection Protections for short circuit, overload and over voltage 3 year warranty

Spec

  • Quantity:1piece
  • Output Voltage : 5V dc
  • Output Current : 3A
  • Power Rating : 15W
  • Number of Outputs : 1
  • Input Voltage : 120 → 370 V dc, 85 → 264 V ac
  • Mounting Type : Chassis Mount
  • Package Type : Open Frame
  • Length : 63.5mm
  • Width : 45.7mm
  • Depth : 24mm
  • Weight : 57g
  • Efficiency : 78%
  • Maximum Temperature : +70°C
  • Minimum Temperature : -30°C
  • CODE No.:777-3109
