Electronic/Electrical Parts and Controll Equipments
63-5089-28 NTR4502PT1G P-Channel MOSFET, 1.9 A, 30 V, 3-Pin SOT-23 ON Semiconductor NTR4502PT1G
model:
63-5089-28
brand:
ON Semiconductor
Product Description
Product Model: 63-5089-28Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-5089-28
Product Brand: ON Semiconductor
Features
- P-Channel Power MOSFET, 30V to 500V, ON Semiconductor
Spec
- Quantity：1bag(10pieces)
- Channel Type : P
- Maximum Continuous Drain Current : 1.9 A
- Maximum Drain Source Voltage : 30 V
- Maximum Drain Source Resistance : 350 mΩ
- Maximum Gate Threshold Voltage : 3V
- Maximum Gate Source Voltage : -20 V, +20 V
- Package Type : SOT-23
- Mounting Type : Surface Mount
- Transistor Configuration : Single
- Channel Mode : Enhancement
- Category : Power MOSFET
- Maximum Power Dissipation : 1.25 W
- Minimum Operating Temperature : -55 °C
- CODE No.:773-7897
