63-5086-52 1mΩ 2512 Metal Strip Surface Mount Fixed Resistor ±1% 3W - TLR3A30DR001FTDG TLR3A30DR001FTDG
Electronic/Electrical Parts and Controll Equipments

63-5086-52 1mΩ 2512 Metal Strip Surface Mount Fixed Resistor ±1% 3W - TLR3A30DR001FTDG TLR3A30DR001FTDG

model: 63-5086-52
brand: TE Connectivity

Product Description

Product Model: 63-5086-52Product Brand: TE Connectivity […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-5086-52
Product Brand: TE Connectivity

Features

  • SMD Low Ohmic / Current Sense Resistors - TLR Series. The TLR series high power metal chip resistors for current sensing applications, are constructed to prolong terminal life by having its metal resistive element and barrier layers beneath the solder. TLR resistors are ideal for *** in combination with a range of IC's for battery charge management and low voltage power supplies, where a low ohmic shunt resistor is required to act as a current sensor. TLR s are particularly suited to applications in the automotive industry for sensing in EMU's.

Spec

  • Quantity:1bag(5pieces)
  • Resistance : 1mΩ
  • Technology : Metal Strip
  • Package/Case : 2512 (6432M)
  • Tolerance : ±1%
  • Power Rating : 3W
  • Temperature Coefficient : ±50ppm/°C
  • Series : TLR
  • Minimum Operating Temperature : -55°C
  • Maximum Operating Temperature : +170°C
  • CODE No.:771-7840
