Features

• Hirose HR10A Series Push-Pull Circular Connectors. From Hirose, a selection high-performance plugs, receptacles and jacks from the HR10A series. The micro circular connectors are compact, durable and light weight. With their miniature design, the HR10A connectors provide a perfect solution for high-density applications where space is limited. Featuring a simple push-pull mechanism, connection and disconnection are completed in one smooth action. A five-key polarization system for accurate alignment ensures positive mating and the correct position is established, even when blind mating. Cable mount plugs with male contacts mate with panel mount receptacles with female contacts for cable to panel applications Cable mount plugs with male contacts mate with cable mount jacks with female contacts for cable to cable (in-line) applications Crimp or soldering termination. For suitable contacts see part numbers ; 764-4547 764-4547 and ; 166-4964 166-4964 for female and ; 764-4543 764-4543 and ; 166-4963 166-4963 for male contacts. Two hand crimp tools are available, see part numbers ; 772-7112 772-7112 or ; 772-7115 772-7115. Features and Benefits. Five Key polarization for accurate alignment Single action push-pull coupling mechanism High-density mounting for space saving Compact and lightweight design Solder or crimp contacts. Applications. The HR10A series of connectors are Ideal for *** in commercial, industrial, electronic and electrical small sized equipment. Some of the most common are. Computers and peripherals Audio equipment Video equipment Portable wireless equipment Measuring equipment Instrumentation. FAQ. Q - How robust are the connectors? A - The HR10A connectors are manufactured from tough engineering materials. They are robust and reliable. Q - Are there any accessories? A - A selection of circular dust caps are available for added protection from dust and moisture. Dust caps protect the connector when not in ***. ; 764-5063 764-5063 is a dust cap for shell size 7 connectors ; 764-5060 764-5060 is a dust cap for shell size 10 connectors ; 764-5067 764-5067 is a dust cap for shell size 13 connectors
