3-7755-11 Fume Hood (Low Air Volume Type) 1200 x 750 x 2350 mm ALF2M-12TN
Product Description
Product Model: 3-7755-11Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-7755-11
Product Brand: AS ONE Corporation
Features
- The baffle plate shape and push air provide high containment performance even at low air volumes.
- Containment performance is verified by EN test (European standard/EN14175-3:2003).
- Reducing air volume reduces air conditioning equipment costs, running costs, and environmental impact.
- A status monitor light is provided above the operating switches to show how the fume hood is operating.
Spec
- External Dimensions (mm): 1200 x 750 x 2350
- Inner Dimensions (mm): 1040 x 565 x 1210
- Weight (approx. kg): 265
- Exterior: Steel Material (Powder Coating)
- Interior: Non-asbestos Noncombustible Decorative Plate
- work planes: Trespa
- Front Sash: Tempered Glass (5 mm Thickness), Balance Weight Type, with Opening Limiting Key (Height 400 mm)
- Outlet: 100 VAC 15 A with 2 Consecutive Grounds (Withdrawal Prevention) 1
- internal lighting: LEDs
- Safety Mechanism: Status Monitor Light, Opening Restriction Stopper (with Key), Door Fall Prevention Stopper, Exhaust Delay Timer
- Power: 100 VAC 50/60Hz
- Air flow (m3/min) *: 7
- Duct Connection Port: 200 A
- Required Duct Diameter (Φmm): 200
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *As a sealed push-pull ventilator, it can be reported to the Labor Standards Inspection Office (prior confirmation may be required dep***ing on ***, condition, and area).
