Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 9 points at 37 degrees Celsius
• Storage capacity (L): 27
• External dimensions (mm): 400 x 410 x 685
• Interior dimensions (mm): 300 x 300 x 300
• Convection system: Natural convection air jacket
• Temperature control range: room temperature + 5 ~ 80 degrees C
• Time to reach 37 degrees: About 20 minutes
• Temperature distribution (JTM K05): +/- 0.6 degrees C (at 37 degrees C)
• Temperature variation (JIS): +/- 0.6 degrees C (at 37 degrees C)
• Temperature Gradient (JIS): 2.0 degrees C (at 37 degrees C)
• Temperature control system: PID control, SSR output
• Additional functions: ON Timer, OFF Timer, SV start, ON/OFF Timer
• Safety device
• Indep***ent overtemperature protection device (operating temperature can be set digitally)
• Overcurrent breaker
• Burnout mechanism (heater OFF when sensor is disconnected)
• Heater capacity: 200 W
• Temperature Sensor: Platinum temperature resistor Pt 100 ohm
• Overrise prevention sensor: K thermocouple
• Shelf Pitch/Number of Racks: 35 mm Pitch/7 Racks
• Exterior/Interior: Steel powder coating/Stainless steel (SUS 304)
• Inner door material: Tempered glass
• Vent: 32 mm in diameter x 1
• Weight: approximately 30 kg
• Power Supply: 100 VAC 50/60 Hz Cord Length 2 m 3 P Plug
• Shelf load capacity: 15 kg
• Accessories: 2 shelf boards, 2 shelf rails
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
