Spec

• Inner capacity (L): 27
• Outer dimensions (mm): 400 x 410 x 685
• Inner dimensions (mm): 300 x 300 x 300
• Convection type: Natural convection air jacket
• Temperature control range: R.T. + 5 to 80 °C
• Maximum temperature arrival time: about 20 minutes
• Temperature distribution accuracy (JTM K05): ±0.6 °C (at 37 °C)
• Temperature fluctuation (JIS): ±0.6 °C (at 37 °C)
• Temperature gradient (JIS): 2.0 °C (at 37 °C)
• Temperature control method: PID control and SSR output
• Additional function: ON timer, OFF timer, SV start, ON/OFF timer
• safety device
• *Indep***ence type overheating prevention device (Operation temperature Digital settable)
• *Overcurrent breaker burnout mechanism (Heater OFF when sensor is disconnected)
• Heater capacity: 200W
• Temperature sensor: Pt 100Ω
• Overhead protection sensor: K class thermocouple
• Tana pitch number of step mm: 35 pitch 7 stages
• Exterior/Interior: Steel powder coating/Stainless steel (SUS304)
• Material : tempered glass
• Air outlet: φ32mm x 1 piece
• Weight: about 30kg
• Power supply: AC100V 50/60Hz cord length 2m3P plug
• shelf board, load tolerance: 15kg
• Accessories: shelf board x 2 pieces/shelf board rail x 2 sets
• This product can be ***d for validation services (IQ/OQ).　Please contact us.
• *The Validation Service is a service that performs installation qualification (IQ) and operating performance qualification (OQ) at the customer's site, and submits inspection documents.
