63-5051-95　Vishay IHLP-6767GZ-11 Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 47 μH ±20%　IHLP6767GZER470M11
Electronic/Electrical Parts and Controll Equipments

63-5051-95　Vishay IHLP-6767GZ-11 Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 47 μH ±20%　IHLP6767GZER470M11

model: 63-5051-95
brand: Vishay
category: Electronic/Electrical Parts and Controll Equipments

Product Description

Product Model: 63-5051-95Product Brand: Vishay Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code
Online Consultation

Product Details

Product Model: 63-5051-95
Product Brand: Vishay

Features

  • IHLP6767GZ-11 Series Magnetically Shielded Wire Wound Chokes. Vishay IHLP-6767GZ-11 series high current low profile shielded inductors. The IHLP-6767GZ-11 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction. Frequency range up to 750 kHz Lowest DC Resistance / μH in this package size Halogen-free according to IEC 61249-2-21 definition. Applications include: PDA/****book/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array (FPGA)

Spec

  • Quantity：1piece
  • Inductance : 47 μH
  • Maximum DC Current : 8.7A
  • Package/Case : 6767
  • Length : 17.15mm
  • Depth : 17.15mm
  • Height : 7mm
  • Dimensions : 17.15 x 17.15 x 7mm
  • Shielded : Yes
  • Tolerance : ±20%
  • Maximum DC Resistance : 42.7mΩ
  • Series : IHLP-6767GZ-11
  • Core Material : Metal Composite
  • Maximum Self Resonant Frequency : 4.1MHz
  • Inductor Construction : Wire-Wound
  • CODE No.:748-7621

Related product recommendations

You may also be interested in the following products

63-4851-21　Bourns 1 Gang Continuous Turn Rotary Conductive Plastic Potentiometer with a 3.18 mm Dia. Shaft, 50kΩ, ±20%, 0.25W,　3310Y-001-503L
Electronic/Electrical Parts and Controll Equipments

63-4851-21　Bourns 1 Gang Continuous Turn Rotary Conductive Plastic Potentiometer with a 3.18 mm Dia. Shaft, 50kΩ, ±20%, 0.25W,　3310Y-001-503L

model: 63-4851-21 brand: Bourns
detail
63-4774-92　Signal Construct Green Indicator, Solder Tab Termination, 20 → 28 V, 6mm Mounting Hole Size　SMCP06204
