Electronic/Electrical Parts and Controll Equipments
63-5048-44 Bourns SRN3015 Series Type 3015 Shielded Wire-wound SMD Inductor with a Ferrite Core, 10 μH ±20% Wire-Wound 1A Idc SRN3015-100M
Product Description
Product Model: 63-5048-44Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 63-5048-44
Product Brand: Bourns
Features
- AEC-Q200. SRN3015 Series Semi Magnetically Shielded Wire Wound Chokes. Bourns SRN3015 series miniature SMD semi-shielded power inductors feature an inductance range of 1 to 47uH and a rated current up to 2.2A, operating temperature of -40°C to +125°C. These inductors are suitable for the automotive industry and are AEC-Q200 qualified. Applications. Automotive systems: Driver assistant, information, lighting, entertainment DC-DC convertors Power supplies Televisions Digital video
Spec
- Quantity：1bag(10pieces)
- Inductance : 10 μH
- Maximum DC Current : 1A
- Package/Case : 3015
- Length : 3mm
- Depth : 3mm
- Height : 1.5mm
- Dimensions : 3 x 3 x 1.5mm
- Shielded : Yes
- Tolerance : ±20%
- Maximum DC Resistance : 276mΩ
- Series : SRN3015
- Core Material : Ferrite
- Maximum Self Resonant Frequency : 45MHz
- Maximum Operating Temperature : +125°C
- CODE No.:743-5071
