Spec

• Impeller stirring
• Reaction vessel/Number of bottles: Separable flasco/1 ~ 4 bottles
• Synthetic scale: 50 mL/100 mL/250 mL (choice)
• Temperature control range (aluminum block temperature): - 20 ~ 200 C (4 x individual temperature control) * A cooling water circulator is required.
• Temperature control accuracy: +/- 0.5 K (- 20 ~ 100 deg. C)/+/- 0.1 K (100 ~ 200 deg. C)
• Speed range: Impeller/0, 125 ~ 1000 rpm (4 x individual stirring), Stirrer/0, 100 ~ 1000 rpm (4 x individual stirring)
• Maximum heating rate: Tr < 5.3 K/min, Tj < 19.3K/min(5°C→95°C)
• Maximum cooling rate: Tr < 7.2 K/min, Tj < 27.8K/min(95°C→5°C)
• Maximum heat removal: 0.74 ~ 1.1 W/g (200 mL water in a glass reactor)
• Temperature control: Reactor, Jacket, Insulation, Gradient, Isothermal, Heating and Cooling P.I.D, Cascade
• Dropping Control: Weight Dropping or Deposition Dropping (1 ~ 4 reams)
• Stirring control: Impeller stirrer (selective)
• pH control (optional): 0 ~ 14 pH, acid or base (1-liquid control or 2-liquid control)
• Calorimetry: Heat flow, specific heat, reaction heat calculation, calibration heater, with CalGraph for recalculation and analysis
• Setting and recording: Setting and recording for each experiment, automatic recording of parameters such as temperature and dripping
• Tr*** graph export: Real-time pen, with function to retrieve historical pen display and saved data to Excel
• Safety features: Emergency cooling function/Automatic operation at reactor control End-step setting, earth leakage/overcurrent breaker with emergency program setting, aluminum block indep***ent overrise detector, motor overload protection, software self-diagnosis function (Upper temperature, temperature rise speed, motor overload), communication error
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 642 x 510 x 380 mm
• Weight: approximately 53 kg
• Power input/voltage: 20 A, 2.0 kVA AC 100 V 50/60 Hz
• *A personal computer is included.
• *Temperature and pH sensors are sold separately.
• *The temperature unit K is Kelvin (absolute temperature).
• Code: 254030
