Spec

• Microwave irradiation system: Single mode (continuous wave)
• Reaction method: Liquid phase synthesis (Atmospheric pressure response, pressurized response)
• Synthetic scale (adapter replaceable type): Under atmospheric pressure reaction/1 ~ 5 mL/5 ~ 10 mL/10 ~ 30 mL/30 ~ 50 mL, Under pressurization reaction: 3 ~ 5 mL
• Stirring method: Magnetic stirrer
• Temperature control range: - 13 ~ 200 C (aluminum block thermostat)
• Temperature display resolution: 0.1 degrees C (Reactor temperature, aluminum block temperature)
• Temperature control accuracy: reactor temperature +/- 0.5 degrees C, aluminum block +/- 0.5 degrees C (water)
• Output control range (W): 0 W to 100 W
• Microwave warming rate: 1.7 ~ 2.9 C/sec (water)
• Speed range: 0 rpm, 100 ~ 2000 rpm
• Control: Laptop (included)
• Temperature control: Heating/cooling P.I.D (aluminum block thermostat), heating P.I.D (microwave output), cascade (reactor temperature), external temperature control, internal temperature/heat/reflux control (optional: optical fiber temperature sensor)
• Program: constant value operation, 1 step, 2 steps, auto stop
• Data recording and reporting: Temperature, power, time, pressure, reaction rate, automatic reporting (PDF file)
• exporting: CSV files
• Microwave absorption measurement with microwave absorption calibration function
• Monitoring reaction rate: by using calorific mode
• Safety features: Leakage/overcurrent breaker, alarm (Oscillator reflection wave upper limit, oscillator temperature upper limit, reactor temperature upper limit, jacket temperature upper limit, microwave leakage, sensor disconnection, pressure upper limit, motor overload protection, temperature overrise prevention, communication alarm)
• Oscillation frequency and output power: 2.45 GHz and 100 W (Single-mode TE 10, semiconductor oscillator)
• Sensor: Optical fiber temperature sensor with glass protective tube (optional)
• Operating ambient temperature range: 18 ~ 28 degrees C
• External dimensions: 380 (460) x 498 x 442 mm/* Dimensions in () include projections.
• Weight: approximately 45 kg
• Power input/voltage: 11 A/100 VAC 50/60 Hz
• Code: 271910
