Spec

• Flow type (with separate liquid pump)
• Reaction vessel: Stainless steel column glass column tube (optional)
• Corresponding column sizes: Inner diameter 3, 5, 10 mm x length 50, 100 mm
• Maximum working pressure: less than 1 MPa
• Temperature control range: 50 ~ 200 degrees Celsius (aluminum block temperature)
• Temperature control accuracy: 1.0 degrees Celsius or less (aluminum block temperature)
• Temperature control: aluminum block jacket control, heating P.I.D control
• Temperature setting and display: Sheet key input and digital display
• Sample inlet: 1 solution system/double tube gas system/1 solution system (optional)
• Safety functions: Temperature controller self-diagnosis function (variable upper limit temperature/sensor error) Indep***ent overrise detector (temperature f***), leakage/overcurrent breaker
• Wetted Part Material: PTFE/PEEK/Perflo (R)/SUS 316/Glass
• Connection Piping and Connection Screw Standards: Outer Diameter 1/16 "Tube No. 10 -32 NF
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions and mass: Constant temperature chamber/124 x 163 x 214 mm/2.9 kg, control/80 x 220 x 151 mm/1.8 kg
• 2.0 A 200 VA/100 VAC 50/60 Hz
• *No columns are included. An optional column set is required.
• Code: 267950
