Spec

• Ferromagnetic magnetic stirrer
• Reaction vessel/number: Various reaction vessels/1 ~ 5 bottles (maximum 20 bottles)
• Synthetic scale: 0.5 ~ 60 mL (dep***ing on the reaction vessel ***d)
• Temperature control range (aluminum block temperature): - 23 ~ 160 C (130 C: 50 ~ 60 mL) Individual temperature control x 5 * A cooling water circulator is required.
• Temperature control accuracy: +/- 0.5 degrees C
• Speed range: 100 ~ 2000 rpm (Same rotational speed x 5 for 1 mL of water), 100 ~ 1100 rpm (Same rotational speed x 5 when 60 mL of water is ***d)
• Temperature setting and display: Sheet key input and digital display (- 40.0 ~ 160.0 C)
• Stirring setting and display: Volume setting and digital display (20 ~ 2000 rpm)
• Gas replacement: by vacuum drawing and inert gas introduction (dep***ing on container)
• Reflux: None/Reflux adapter/Coolant manifold
• Additions of reagents: pipettes, syringes and dropping funnels (with common mating) can be added under inert conditions.
• Reaction observation: By slit in aluminum block (with lighting)
• Safety features: Leakage/overcurrent breaker, temperature f***, temperature controller self-diagnosis (Variable upper limit temperature, sensor error), double chamber, drop tray, aluminum block mounting detection, motor overload protection
• Wetted part material: Glass, Teflon (R)
• Cooling Water Connection Port: Cooling Cartridge/Outer Diameter 12 mm Hose Port, Manifold/Outer Diameter 12 mm Hose Port (Cooling Hose sold separately)
• Gas connection bore: Electric part air purge/outer diameter 6mm one-touch joint
• Operating ambient temperature range: 5 ~ 35 degrees C
• Weight: 23 kg
• External dimensions: 465 x 340 x 295 mm
• Power input/voltage: 6.5 A, 650 V A/AC 100 V 50/60 Hz
• *Performance is measured at room temperature of 20 degrees Celsius, rated power supply voltage, no load and with cooling water circulator.
• *Various reaction containers, glass parts, test tube adapters, and reflux adapters are sold separately.
• Code: 226490
