Electronic/Electrical Parts and Controll Equipments
63-5040-51 Hirose FH12 0.5mm Pitch 24 Way Right Angle SMT Female FPC Connector, ZIF Bottom Contact FH12-24S-0.5SH(55)
Product Description
Product Model: 63-5040-51Product Brand: Hirose Features […]
Contact Us
Product Details
Product Model: 63-5040-51
Product Brand: Hirose
Features
- Hirose FH12 Series 0.5 mm FPC/FFC Connectors. FH12 series ZIF (zero insertion force) FPC/FFC connectors with a 0.5mm pitch. These FPC connectors feature a one-touch rotating ZIF actuator for easy operation. Once fully closed the actuator produces a tactile click to confirm that mating is complete. FH12 series FPC/FFC connectors with their one-touch ZIF rotating actuator occupy less space on the PCB than versions with slide locking mechanisms enabling high density mounting. These FH12 series FPC/FFC connectors are available with a bottom contact configuration (FH12) or a top contact configuration (FH12A). Features and Benefits. One-touch rotating ZIF actuator Tactile click to confirm mating PCB space saving design Supports high density mounting Top and bottom mounting contact configurations. Applications. Suitable for *** in a broad range of applications such as mobile phones, GPS, ****book PCs, data terminals, LCD TVs, digital and video cameras and other small hand held devices that connect to an LCD
Spec
- Quantity:1bag(5pieces)
- Number of Contacts : 24
- Contact Material : Phosphor Bronze
- Pitch : 0.5mm
- Mounting Type : Surface Mount
- G***er : Female
- Termination Type : ZIF Bottom Contact
- Body Orientation : Right Angle
- Current Rating : 500mA
- Voltage Rating : 50 V ac
- Series : FH12
- Number of Rows : 1
- Contact Plating : Gold
- Minimum Operating Temperature : -40°C
- CODE No.:738-8827
