63-5036-94 Amphenol FCI 10090926 Series, 26 Way Right Angle Through Hole PCB D-sub Connector Plug, 2.29mm Pitch 10090926-P264XLF
Product Description
Product Model: 63-5036-94Product Brand: Amphenol FCI Fe […]
Contact Us
Product Details
Product Model: 63-5036-94
Product Brand: Amphenol FCI
Features
- For HD D-Sub connectors with screw locks see stock number ; 736-1510 736-1510 typical. D-Sub Compact HD with Clinch Nuts. These FCI D-Subminiature High-Density connectors are suitable for applications requiring robust and reliable connectors such as Telecommunications, Data, Consumer, Industrial, Military, Instrumentation and Medical markets. The High-Density range gives Input - Output interconnects to meet all design requirements and addresses the increasing needs for high density packaging. These HD D-Sub connectors have UNC 4-40 Clinch nuts with Board locks.
Spec
- Quantity：1piece
- Number of Contacts : 26
- G***er : Male
- Body Orientation : Right Angle
- Mounting Type : Through Hole
- Pitch : 2.29mm
- Current Rating : 2.5A
- Housing Material : Thermoplastic
- Voltage Rating : 250 V
- Length : 39.24mm
- Width : 16.2mm
- Depth : 12.55mm
- Dimensions : 39.24 x 16.2 x 12.55mm
- Contact Material : Copper Alloy
- CODE No.:736-1526
