63-5036-58 Sensata / Crydom 7 A SP-NC Solid State Relay, DC, Surface Mount, Transistor, 60 V dc Maximum Load DC60S7-B
model:
63-5036-58
brand:
Sensata / Crydom
Product Description
Product Model: 63-5036-58Product Brand: Sensata / Crydo […]
Contact Us
Product Details
Product Model: 63-5036-58
Product Brand: Sensata / Crydom
Features
- UL, cUL. Panel Mount - DC60 Series. Solid state relays with bi-polar transistor output Ratings of 7A at 60 Vdc AC or DC control voltage Panel mount relay package Screws and Saddle Clamps to allow electrical connection 4000 Vrms isolation voltage Operation temperature of -30 → +80 °C Thermally conductive Epoxy body housing to aid heat dissipation NO and NC output types available
Spec
- Quantity：1piece
- Minimum Load Current : 20 mA
- Maximum Load Current : 7 A
- Mounting Type : Surface Mount
- Minimum Load Voltage : 3 V dc
- Maximum Load Voltage : 60 V dc
- Minimum Control Voltage : 3.5 V dc
- Maximum Control Voltage : 32 V dc
- Switching Type : DC
- Contact Configuration : SP-NC
- Terminal Type : Screw
- Output Device : Transistor
- Maximum Turn On Time : 0.1 ms
- Dimensions : 45.7 x 19.8 x 58.4mm
- Load Voltage Range : 3 → 60V dc
- CODE No.:736-0882
