63-5018-83 TE Connectivity Dynamic 1000 Female Connector Housing, 2.5mm Pitch, 4 Way, 2 Row 2-1827864-2
model:
63-5018-83
brand:
TE Connectivity
Product Description
Product Model: 63-5018-83Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-5018-83
Product Brand: TE Connectivity
Features
- TE Connectivity Dynamic 1200 Series Receptacle Housings. These Dynamic D-1200 series receptacle housings are part of the Dynamic D-1000 series connector system which is the smallest signal connector in the Dynamic connector range. The compact design of the Dynamic D-1000 series enables it to be used in applications where space saving is required in miniaturized equipment applications. These Dynamic D-1200 receptacle housings have a 2.5mm pitch and feature a housing lance structure to help prevent contact lance breakage during terminal process handling. A housing lock and keying are incorporated into the design for accurate and secure mating. These housings are also colour coded with the circuit number marked on them for accurate mating identification and wiring. The socket contacts for these Dynamic D-1200 series receptacle housings must be purchased separately, see stock number ; 706-0416 706-0416 typically
Spec
- Quantity:1bag(5pieces)
- Number of Contacts : 4
- Number of Rows : 2
- Pitch : 2.5mm
- Gender : Female
- Series : Dynamic 1000
- Body Orientation : Straight
- Length : 7.6mm
- Width : 12.45mm
- Depth : 11.3mm
- Housing Material : PET
- CODE No.:720-1528
