Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 3 points at 37 degrees Celsius
• Material: Body/Steel, Interior/Aluminum, Inner Door/PMMA (Acrylic)
• External dimensions: 450 x 340 x 335 mm
• Internal dimensions: 288 x 190 x 222 mm
• Contents: 12 L
• Temperature setting range: 5 ~ 50 degrees C
• Temperature setting unit: 0.1 degrees C
• Cooling capacity: Room temperature - 15 ~ 16 degrees Celsius (about 1 hour)
• Accuracy of temperature distribution: below +/- 1 °Celsius (at 37 °Celsius)
• Temperature control method: PID control
• Temperature Sensor: K thermocouple
• Convection system: Forced convection system
• Power consumption: Up to 100 W
• Power supply: 100 VAC 50/60 Hz
• Power cord: 2 m (2P plug)
• Weight: 24 kg
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *Since this product is a physical and chemical culture and refrigeration equipment, it may not be ***d for medical treatment or similar activities or purposes.
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
