Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 3 points at 37 degrees Celsius
• Temperature setting range (deg. C): room temperature + 5 ~ 60
• Internal dimensions (mm): 312 x 220 x 157
• External dimensions (mm): 491 x 296 x 291
• Natural convection system
• Temperature distribution width: 2 degrees Celsius (37 degrees Celsius setting)
• Sensor: Platinum temperature resistor Pt 100 ohm
• Temperature control system: PID control, SSR output
• Temperature setting unit: 1.0 degrees C
• Timer function: ON/OFF/ON/OFF/SV Timer
• Timer setting range: 1 minute to 99 hours 59 minutes (in 1-minute increments)
• Heater capacity: 80 W
• Power supply: 100 VAC 50/60 Hz 1 A
• Power cord length: 1.5 m (3 P plug)
• Safety device: Overtemperature protection device/overcurrent breaker/sensor breakage alarm
• Exterior: Steel Baked Paint
• Interior: Aluminum
• Weight: 9.2 kg
• Accessories: 2 shelf boards
• *If you would like to request a local IQOQ, please contact us separately. We need your installation address for the estimate.
