Spec

• Heater Capacity: 500 W
• Heating Temperature Range: Normal Temperature ~275°C
• Vacuum Chamber Temperature Control Range: Room Temperature ~150°C
• Maximum temperature reached: 275°C
• Degree of vacuum: 133 Pa (1Torr)
• Vacuum Chamber Material: Stainless Steel (SUS304)
• Observation window size: 280 x 270 mm
• Vacuum Valve Hose Nipple Diameter: φ8mm
• With Timer Function
• Power: 100 VAC 50/60Hz
• Power Cord: Approx. 1.5 m (3P Plug)
• Interior Dimension (mm): 300 x 300 x 275
• Weight: Approx. 31 kg
• Accessory: Gold Rack x 2
• Recomm***ed Pump: (1-672-07) Oil Rotary Vacuum Pump G-50SA
• *Please be careful when selecting a product beca*** the temperature of the product to be dried will rise significantly from the internal temperature.
• This product is compatible with the validation service (IQ/OQ). Please contact us.
• *The validation service is a service where installation qualification (IQ) and operation qualification (OQ) are performed at the customer's site and an inspection report is submitted.
