63-5011-36 Bourns TBU-CA065-200-WH, Bi-Directional TVS Diode, 2-Pin DFN TBU-CA065-200-WH
Product Description
Product Model: 63-5011-36Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 63-5011-36
Product Brand: Bourns
Features
- UL. Bourns TBU-CA Series TBU High Speed Protectors. Bourns Transient Blocking Unit (TBU) electronic current limiters (ECL) are circuit protection devices triggered by excessive voltage or current and designed as an optimal circuit protection solution for industrial controls, medical electronics, automated test systems, and military and aerospace applications. They are low capacitance, single bi-directional, high speed, resettable devices which protect - within rated limits - against faults ca***d by short circuits, AC power cross, induction and lightning surges. Special features include ultra-fast over current protection, in a wide range of trigger currents and voltages, and reduced form factors to save board space. The TBU can be ***d for protection on Ethernet, RS-485, HART and other ports where dangerous surge and power cross events may occur. It can also be ***d in telecom applications, providing a barrier to surges while allowing high frequency signals such as VDSL2 to pass through without damage to the circuit. For sensitive electronics applications the TBU eliminates the need for large shunt protection devices by stopping - in less than one microsecond - the damaging currents from reaching protected circuits. The TBU also offers significantly lower let-through energy and overshoot protection, which reduces stress on the PCB for increased reliability and product life. Bourns TBU protection technology limits the energy allowed into sensitive electronics without loading high data rate lines with capacitance. This enables designers to place high performance protection on even their highest bandwidth applications. Superior circuit protection Overcurrent and overvoltage protection Blocks surges up to rated limits High speed performance Small SMT package Operating temperature range -40°C to +125°C Storage temperature range -65°C to +150°C Maximum junction temperature +125°C ESD: IEC 61000-4-2
Spec
- Quantity:1bag(5pieces)
- Direction Type : Bi-Directional
- Maximum Clamping Voltage : 650V
- Mounting Type : Surface Mount
- Package Type : DFN
- Maximum Reverse Stand-off Voltage : 20V
- Pin Count : 2
- Maximum Peak Pulse Current : 0.4A
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +125 °C
- Width : 4mm
- CODE No.:717-3439
