63-5009-98 1 Output Filtering SMPS Transformer, 100μH 78601/4C
Electronic/Electrical Parts and Controll Equipments

63-5009-98 1 Output Filtering SMPS Transformer, 100μH 78601/4C

model: 63-5009-98
brand: Murata Power Solutions

Product Description

Product Model: 63-5009-98Product Brand: Murata Power So […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-5009-98
Product Brand: Murata Power Solutions

Features

  • Pulse Transformer 786 Series. General purpose pulse transformers ***d in coupling, thyristor/triac firing and small sized switch mode power supply applications The standard turns ratios may be modified by connecting any two windings in series Can also be ***d as a common mode choke in filtering applications

Spec

  • Quantity:1piece
  • Number of Outputs : 1
  • Mounting Type : Through Hole
  • Application : Filtering
  • Inductance : 100µH
  • Termination Type : Pin
  • Length : 9.52mm
  • Width : 9mm
  • Depth : 6.35mm
  • Dimensions : 9.52 x 9 x 6.35mm
  • Isolation Voltage : 1kV
  • Leakage Inductance : 0.19µH
  • CODE No.:715-6949
