Product Details

Product Model: 63-5003-02
Product Brand: Littelfuse

Features

  • Tyco PolySwitch™ PTC Devices AHEF Series. TE AHEF series f***s are automotive-specific versions of PolySwitch PPTC devices qualified and sold under the PS400 specification which is derived from AEC-Q200, the standard for electronic components ***d in the automotive industry. Applications they are typically ***d include telematics, infotainment and navigations systems, Liquid Crystal Display (LCD) back-light heaters, power and cigarette lighter outlets, plugs and adapter/chargers, motor and motor circuit protection including power door-locks, mirrors, lumbar pumps, seats, sunroofs, windows, air-flow detection and overcurrent protection in HVAC and cooling fan systems. Overcurrent and overvoltage circuit protection devices Resettable and single-*** overcurrent devices Wide range of form factor and termination methods Products meet applicable automotive industry standards Devices compatible with high-volume electronics assembly RoHS compliant

Spec

  • Quantity:1bag(10pieces)
  • Lead Orientation : Radial
  • Trip Current : 10A
  • Time to Trip : 9s
  • Hold Current : 5A
  • Voltage Rating : 32V dc
  • Maximum Current : 100 A
  • Minimum Resistance : 0.015Ω
  • Maximum Resistance : 40mΩ
  • Power Dissipation : 5.3W
  • Body Height : 24.1mm
  • Body Length : 14mm
  • Body Width : 3.8mm
  • Wire Pitch : 4.3 → 5.8mm
  • Wire Length : 11.5mm
  • Wire Diameter : 20AWG
  • CODE No.:712-7521
