63-4999-16 Phoenix Contact PLC-RPT-120UC/ 1AU/SEN Series 110V ac/dc DIN Rail Interface Relay Module, SPNO 2900314
Electronic/Electrical Parts and Controll Equipments

63-4999-16 Phoenix Contact PLC-RPT-120UC/ 1AU/SEN Series 110V ac/dc DIN Rail Interface Relay Module, SPNO 2900314

model: 63-4999-16
brand: Phoenix Contact

Product Description

Product Model: 63-4999-16Product Brand: Phoenix Contact […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4999-16
Product Brand: Phoenix Contact

Features

  • PLC-PT Relay, Actuator Series and Sensor Series, with Push-In Terminal (PIT). All connections for sensors or actuators go directly onto the coupling relay No additional modular terminal blocks for supply (sensor version) or output (actuator version) Fast plug-in connection of the PLC and other peripherals Gold-plated AgSnO terminals available Solid State versions available Feather-light, direct connection of conductors starting from 0.34 mm 2 without tools. The connection of small cross sections from 0.14 mm 2 – is done using all common screwdrivers and the actuation lever The gas-tight conductor contacting also fulfills special criteria, such as the vibration test in acc. with the railway standard EN 50155

Spec

  • Quantity:1piece
  • Coil Voltage : 110V ac/dc
  • Switching Current : 10 A
  • Mounting Type : DIN Rail
  • Terminal Type : Surface Mount
  • Length : 94mm
  • Series : PLC-RPT-120UC/ 1AU/SEN
  • Height : 80mm
  • Dimensions : 94 x 6.2 x 80mm
  • Contact Material : Gold Plated
  • Input Current : 3.5mA
  • Turn On Time : 6ms
  • CODE No.:711-2699
