63-4988-29 TE Connectivity Dynamic 5000 Male Connector Housing, 10.16mm Pitch, 3 Way, 1 Row 2-353047-3
Electronic/Electrical Parts and Controll Equipments

63-4988-29 TE Connectivity Dynamic 5000 Male Connector Housing, 10.16mm Pitch, 3 Way, 1 Row 2-353047-3

model: 63-4988-29
brand: TE Connectivity

Product Description

Product Model: 63-4988-29Product Brand: TE Connectivity […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4988-29
Product Brand: TE Connectivity

Features

  • For mating D-5200 Series Headers see stock number ; 706-8022 706-8022 typical. For D-5000 Series Contacts see stock number ; 680-5107 680-5107 typical. TE Connectivity DYNAMIC D-5200S and D-5200M 10.16 mm Tab and Receptacle Housings. Dynamic D-5200 series tab and receptacle connector housings with a compact, vibration resistant design and high current capacity. The D-5200S versions have a standard single row configuration and the D-5200M have a modular dual row configuration. These D-5200 connector housings feature locking lances to secure the contacts into place and to prevent damage to them during mating. An audible click is produced to indicate that the contact is fully secured in the housing. These D-5200 crimp housings feature keying ribs to prevent mismating and movement or twisting between the housings when mated. Locking levers on either side of the housing provide a secure mating connection with an audible click as positive mating assurance. A fitting confirmation line on the housing provides additional visual confirmation. Crimp receptacle and tab contacts for these Dynamic D-5200 connector housings must be purchased separately. Features and Benefits. Compact, vibration resistant design Locking lances for secure contact retention Keying ribs to prevent mismating and movement Locking levers for secure mating connection Audible click for mating assurance Fitting confirmation line for visual mating assurance. Product Application Information. These DYNAMIC D-5200S connectors are suitable for *** in high current power line applications.

Spec

  • Quantity:1piece
  • Number of Contacts : 3
  • Number of Rows : 1
  • Pitch : 10.16mm
  • G***er : Male
  • Mounting Type : Cable Mount
  • Series : Dynamic 5000
  • For Use With : Wire-to-Board Connector
  • Body Orientation : Straight
  • Length : 57mm
  • Width : 16.54mm
  • Depth : 47mm
  • Housing Material : PET
  • CODE No.:706-4496
