63-4987-61 EPCOS SIMID Series Type 1210 (3225M) Wire-wound SMD Inductor with a Ferrite Core, 10 μH ±10% Wire-Wound 500mA Idc Q:12 B82422H1103K000
Product Description
Product Model: 63-4987-61Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-4987-61
Product Brand: EPCOS
Features
- Epcos 1210 B82422H SIMID Series Wire Wound Inductors. From Epcos, the SIMID Series Wire Wound Inductors features is capable of handling very high currents. With a flame retardant encapsulation, the SIMID series of wire wound inductors have a high temperature range, and are well suited to DC/DC converters and switch mode power supplies. Features and Benefits: Laser welded winding Ferrite drum core Suitable for reflow soldering acc. JEDEC J STD 020C Qualified to AEC-Q200
Spec
- Quantity：1bag(10pieces)
- Inductance : 10 μH
- Maximum DC Current : 500mA
- Package/Case : 1210 (3225M)
- Length : 3.2mm
- Depth : 2.5mm
- Height : 2.2mm
- Dimensions : 3.2 x 2.5 x 2.2mm
- Tolerance : ±10%
- Maximum DC Resistance : 460mΩ
- Series : SIMID
- Core Material : Ferrite
- Maximum Self Resonant Frequency : 30MHz
- Minimum Quality Factor : 12
- CODE No.:706-2866
