63-4983-50 5 Way Preci-Dip Straight Through Hole 1.27mm SIL Socket, Solder, 1A 100 V ac, 150 V dc 851-87-005-10-001101
Electronic/Electrical Parts and Controll Equipments

63-4983-50 5 Way Preci-Dip Straight Through Hole 1.27mm SIL Socket, Solder, 1A 100 V ac, 150 V dc 851-87-005-10-001101

model: 63-4983-50
brand: Preci-Dip

Product Description

Product Model: 63-4983-50Product Brand: Preci-Dip Featu […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-4983-50
Product Brand: Preci-Dip

Features

  • UL 94V-0. 1.27 mm IC Socket Connectors. These Swiss Preci-dip IC Ultraminiature PCB Socket Connector headers are solder tail Through Hole or SMD perp***icular Gull-Wing mount. Mating pin Ø 0.38 mm → 0,5 mm The Through Hole headers have a Tail length of 2.3 mm for SIL and 2.4 mm for DIL The SMD mounting headers are perp***icular Gull-Wing type Sockets have Tin plated Brass sleeves with Flash Gold plated Beryllium Copper (4 finger) contact clips

Spec

  • Quantity:1bag(5pieces)
  • Number of Contacts : 5
  • Contact Material : Beryllium Copper, Brass
  • Contact Plating : Gold, Tin
  • Pitch : 1.27mm
  • Termination Method : Solder
  • Mounting Type : Through Hole
  • Housing Material : Glass Fibre Reinforced PCT
  • Current Rating : 1A
  • Voltage Rating : 100 V ac, 150 V dc
  • Dimensions : 6.76 x 2.2 x 4.1mm
  • Depth : 4.1mm
  • Length : 6.76mm
  • Maximum Operating Temperature : +125°C
  • Minimum Operating Temperature : -55°C
  • Width : 2.2mm
  • CODE No.:702-3050
